Built for non-stop, large-batch production, Grand Machinery high speed tablet presses compress up to 153,000 tablets per hour with forces up to 150KN — combining GMP-compliant construction, PLC intelligent control, and double discharge options for pharmaceutical, food, and industrial applications.
Three platforms, one standard: uncompromising speed with stable, pharmacopeia-grade tablet quality. From the double-discharge GZPK660 to the salt-industry specialist GZPK720 and the fully enclosed GZP500, every Grand Machinery high speed tablet press pairs high output with the precision and safety your production line demands.
GZPK660 High Speed Tablet Press features a high level of automation, excellent operational performance, superior stability, and low noise levels, representing leading-edge technology in the domestic market. Based on advanced tablet press technology, this series utilizes an AC variable-frequency motor with stepless speed regulation to drive the turret via a worm gear mechanism, enabling the efficient compression of granules or powders.
GZPK720 High Speed Tablet Press is a high-speed, double-sided discharge tablet press designed specifically for the efficient, high-volume production of salt and industrial tablets. Equipped with 51 punch stations, the machine features main and pre-compression forces of up to 150 kN and a maximum production capacity of 153,000 tablets per hour.
The GZP500 High Speed Tablet Press is a high-performance, double-press rotary machine engineered for large-batch production in the pharmaceutical, food, chemical, and electronic industries. Featuring a fully enclosed stainless steel body, advanced PLC human-machine interface control, and robust pressure protection, it efficiently compresses granular raw materials—including difficult-to-form items—into reliable round or irregular tablets while ensuring high safety, precision, and compliance with GMP standards.
Speed means nothing without stability. Our high speed tablet press range is engineered to hold tablet weight, hardness, and thickness within tight tolerances — hour after hour, at full line speed.
Advanced PLC human-machine interfaces centralize speed, pressure, and fill-depth adjustments, with real-time monitoring that keeps quality parameters within specification automatically.
Compatible with widely used punch and die configurations (including 10D, 14B, and 17-die replacements), making tooling sourcing and changeover simple wherever you are in the world.
AC variable-frequency motors with worm gear turret drive deliver stepless speed regulation, smooth acceleration, and low noise levels — protecting tooling life and operator comfort.
Wherever massive volumes of powder must become tablets — fast — Grand Machinery is on the line.
High-speed, GMP-ready tablet production for prescription drugs, generic medicines, and herbal formulations with strict weight and hardness consistency.
Vitamin, mineral, and supplement tableting including bi-layer and combination tablets, from pilot batches to mass production.
Pressing for candy tablets, effervescent formats, seasoning tablets, and food-grade compression applications.
Fertilizer pellets, detergent tablets, catalyst and electronic material pressing with durable tooling for abrasive powders.
Building a complete high-speed line? Pair your high speed tablet press with our tablet coating machine, metal detection, and blister packaging solutions.
Both compress powder into tablets — but at scale, the economics diverge quickly. Here is how a high speed tablet press compares with a standard rotary machine.
| Dimension | High Speed Tablet Press | Standard Rotary Tablet Press |
| Output range | Up to 153,000 tablets/hour | Typically 10,000–40,000 tablets/hour |
| Punch stations | Up to 51 stations | 5–36 stations |
| Compression force | Up to 150KN main & pre-compression | Up to 100KN |
| Discharge | Double-sided discharge options | Single discharge |
| Control level | Advanced PLC HMI with real-time monitoring | PLC or mechanical control |
| Best suited for | Large-batch, single-SKU continuous production | Mid-volume, frequent changeover production |
| Investment & ROI | Higher upfront, lowest cost per tablet | Lower upfront, higher labor per tablet |
Producing under 50,000 tablets/hour? A standard rotary model may fit better — browse our rotary tablet press range. Running bigger volumes, or not sure? Our engineers will benchmark your recipe against both platforms within 24 hours.
At 100,000+ tablets per hour, the wrong specification is expensive to fix. Run through these five checks before requesting a quote.
Match punch stations and turret speed to real demand: the GZPK660 and GZPK720 platforms cover high-volume continuous production up to 153,000 tablets/hour.
Difficult-to-form, hygroscopic, or brittle powders need strong pre-compression (up to 150KN in this range) and robust pressure protection to avoid capping and lamination at speed.
Confirm diameter, shape (round or irregular), and weight tolerance windows at production speed — not just in lab trials. High-speed compression amplifies flow and fill issues.
Single vs. double discharge changes line layout and changeover time. Double-sided models (GZPK660, GZPK720) maximize uptime for single-SKU, high-volume runs.
Regulated buyers should specify GMP-compliant enclosed bodies, PLC data interfaces, and dust extraction at inquiry stage; confirm spare punch and die availability before signing.
Send your recipe & target output — Our business managers will contact you for detailed customization within 24 hours.
Serious about high-volume tableting? These are the questions high-volume buyers ask our engineers most — before they commit to a platform.
A high speed tablet press is a rotary tablet compression machine engineered for maximum output — typically 100,000 tablets per hour and beyond. Grand Machinery’s range uses up to 51 punch stations, double-sided discharge, and main plus pre-compression forces up to 150KN to reach 153,000 tablets/hour while holding tight weight and hardness tolerances.
A standard rotary tablet press produces roughly 10,000–40,000 tablets per hour. Our high speed models multiply that several times over: the GZPK720 with 51 punch stations reaches up to 153,000 tablets/hour, meaning one machine can replace multiple standard presses on a large-batch line.
Large-batch pharmaceutical production, food and supplement tableting, and especially salt and industrial tableting — the GZPK720 is purpose-built for high-volume salt tablet production. The GZP500 also handles difficult-to-form chemical and electronic materials.
Yes. With main and pre-compression forces up to 150KN, progressive densification, and robust pressure protection, our presses compact sticky, hygroscopic, or difficult-to-form powders into reliable round or irregular tablets — at full production speed, not reduced speeds.
Double discharge means tablets exit from both sides of the turret (as on the GZPK660 and GZPK720). It reduces mechanical stress, enables higher turret speeds, and keeps output continuous — key advantages when a single SKU runs for days at a time.
Every Grand Machinery high speed tablet press ships with manuals and video guidance, plus remote installation support and operator training. Wear parts and punch tooling are stocked for fast global shipping, and our engineers provide lifetime technical support.
